Destription:

The Explosion Proof Linear Fixture series features is a 90 minute emergency backup battery in 12W designed for hazardous environments where Zone 1 and Zone 2 with explosive gas atmosphere or explosive dust atmosphere may be present.

This battery backup lighting fixtures made of the die-cast aluminum and the PC cover. Good heat, and 6J impact resistance.
Installation: pendant, ceiling, pole or more customized.

Adopt to the high light-efficacy LED source, up to 140lm/W, the CCT is 2700K, 3000K, 4000K, 5000K, 5700K, 6500K optional, no flicker, no glare.

The electrophoresis technology and the multiple coats of marine anti-corrosion paint, the all the mounting brackets and accessories are made of 316 stainless steel, UL1598A anti-corrosion standard can for marine location.

If you need UL844 certified of the North American, please visit to Class 1 Division 2 emergency lights.

ATEX: EN IEC 60079-0-2018; EN 60079-7-2015; EN 60079-18-2015; EN 60079-31-2014;
IECEx: IEC 60079-0-2017; IEC 60079-7-2015; IEC 60079-18-2014; IEC 60079-31-2013;

IECEx & ATEX :

• “CAUTION-USEFASTENER WITH YIELD STRESS ≥ 640 MPa”；
• “WARNING – DO NOT OPEN WHEN ENERGIZED”；
• “WARNING – DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE IS PRESENT”；
• “WARNING – ONLY USE CABLES SUITABLE FOR 85°C”；
• " WARNING - DETAILED TEMPERATURE CLASS - SEE INSTRUCTIONS”；
• “THE FLAMPROOF JOINTS ARE NOT INTENDED TO BE REPAIRED”;
• End user shall use certified cable gland or conduit with suitable type of protection for final installation purpose；
• External earthing wire shall be connected when used and the cross-sectional areashall be more than 4mm2 or 10AWG；
• Under rating condition, maximum temperature on the luminaire’s shell shall not be higher than 130℃ for T4.Temperature at cable inlet shall not be higher than allowable limit of the cable applied, to ensure the cable operation normally. The branch point is 83.6℃ and cable entry point is 69.4℃

Description:

This 3ft 4ft Explosion Proof Linear Fixture series features a 90 minute emergency backup battery in 12W designed for hazardous environments where Zone 1 and Zone 2 with explosive gas atmosphere or explosive dust atmosphere may be present.

This battery backup lighting fixtures made of the die-cast aluminum and the PC cover. Good heat, and 6J impact resistance.
Installation: pendant, ceiling, pole or more customized.

Adopt to the high light-efficacy LED source, up to 140lm/W, the CCT is 2700K, 3000K, 4000K, 5000K, 5700K, 6500K optional, no flicker, no glare.

The electrophoresis technology and the multiple coats of marine anti-corrosion paint, the all the mounting brackets and accessories are made of 316 stainless steel, UL1598A anti-corrosion standard can for marine location.

If you need UL844 certified of the North American, please visit to Class 1 Division 2 emergency lights.

IECEx & ATEX :

• “CAUTION-USEFASTENER WITH YIELD STRESS ≥ 640 MPa”；
• “WARNING – DO NOT OPEN WHEN ENERGIZED”；
• “WARNING – DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE IS PRESENT”；
• “WARNING – ONLY USE CABLES SUITABLE FOR 85°C”；
• " WARNING - DETAILED TEMPERATURE CLASS - SEE INSTRUCTIONS”；
• “THE FLAMPROOF JOINTS ARE NOT INTENDED TO BE REPAIRED”;
• End user shall use certified cable gland or conduit with suitable type of protection for final installation purpose；
• External earthing wire shall be connected when used and the cross-sectional areashall be more than 4mm2 or 10AWG；
• Under rating condition, maximum temperature on the luminaire’s shell shall not be higher than 130℃ for T4.Temperature at cable inlet shall not be higher than allowable limit of the cable applied, to ensure the cable operation normally. The branch point is 83.6℃ and cable entry point is 69.4℃

Description:

CES-EX-LN-02P-E series 4ft length emergency explosion proof linear LED fixtures, 40W, 50W, 60W, 65W, 70W, 75W power, with an backup ( 12 Watt ) Li-ion battery that provides energy efficient illumination, the emergency backup provide 1680 lumens for the 1.5 hours.

This linear hazardous location LED fixtures on only obtained UL844 certificate, can used for the hazard location of Class 1 Div 2 Groups A, B, C and D. For design and structure, this emergency hazardous location LED fixtures made of the die-cast aluminum and the PC cover. Good heat, and 6J impact resistance.

In addition, we designed this fixtures for marine location ( UL1598A certificate), we adopt to the electrophoresis technology and the multiple coats of marine anti-corrosion paint, the all the mounting brackets and accessories are made of 316 stainless steel, UL1598A anti-corrosion standard can for marine location.

For the optics, adopt to the high light efficacy LED source, up to 140lm/W, the CCT 2700K, 3000K, 4000K, 5000K, 5700K, 6500K optional, no flicker, no glare.

If you need IECEx and ATEx certified, please visit to 4ft emergency epxlosion proof linear lights of Zone 1.

CUL for Hazloc:

• SUITABLE FOR WET LOCATIONS;
• THIS LUMINAIRE IS ACCEPTABLE FOR OPERATION IN AMBIENT CONDITIONS NOT EXCEEDING __55__ °C (_131 °F);
• MIN 90°C (194°F) SUPPLY CONDUCTORS;
• NO SERVICEABLE PARTS” OR “NO USER SERVICEABLE PARTS. DO NOT OPEN FOR CLEANING.;
• CAUTION - ″TO REDUCE THE RISK OF IGNITION OF HAZARDOUS ATMOSPHERES, DISCONNECT THE LUMINAIRE FROM THE SUPPLY CIRCUIT BEFORE OPENING. KEEP TIGHTLY CLOSED WHEN IN OPERATION.″;
• THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED;
• “CAUTION – RISK OF SHOCK” and “DISCONNECT POWER BEFORE SERVICING”.

Description:

CES-EX-LN-02P-E series 2ft length emergency explosion proof linear LED fixtures with an backup Li-ion battery that provides energy efficient illumination, the emergency backup provide 1680 lumens for the 1.5 hours.

This linear hazardous location LED fixtures on only obtained UL844 certificate, can used for the hazard location of Class 1 Div 2 Groups A, B, C and D. For design and structure, this emergency hazardous location LED fixtures made of the die-cast aluminum and the PC cover. Good heat, and 6J impact resistance.

In addition, we designed this fixtures for marine location ( UL1598A certificate), we adopt to the electrophoresis technology and the multiple coats of marine anti-corrosion paint, the all the mounting brackets and accessories are made of 316 stainless steel, UL1598A anti-corrosion standard can for marine location.

For the optics, adopt to the high light efficacy LED source, up to 140lm/W, the CCT 2700K, 3000K, 4000K, 5000K, 5700K, 6500K optional, no flicker, no glare.

If you need IECEx and ATEx certified, please visit to 2ft emergency epxlosion proof linear lights of Zone 1.

CUL for Hazloc:

• SUITABLE FOR WET LOCATIONS;
• THIS LUMINAIRE IS ACCEPTABLE FOR OPERATION IN AMBIENT CONDITIONS NOT EXCEEDING __55__ °C (_131 °F);
• MIN 90°C (194°F) SUPPLY CONDUCTORS;
• NO SERVICEABLE PARTS” OR “NO USER SERVICEABLE PARTS. DO NOT OPEN FOR CLEANING.;
• CAUTION - ″TO REDUCE THE RISK OF IGNITION OF HAZARDOUS ATMOSPHERES, DISCONNECT THE LUMINAIRE FROM THE SUPPLY CIRCUIT BEFORE OPENING. KEEP TIGHTLY CLOSED WHEN IN OPERATION.″;
• THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED;
• “CAUTION – RISK OF SHOCK” and “DISCONNECT POWER BEFORE SERVICING”.

Description:

This explosion proof emergency flood light fixtures with an emergency backup battery (12W Li-ion battery), the emergency backup lighting provide 1680 lumens for the 1.5 hours. For the normal lighting , the input voltage is AC100 - 277V, 60W, 80W, 100W power optional.

This floodlight explosion proof LED fixtures on only obtained IECEx and ATEX certificate, can used for the Zone 1 Zone 21, Zone 2 Zone 22. For design and structure, this emergency explosion proof light made of the die-cast aluminum and the 8mm high tempered glass. Good heat and 6J impact resistance.

If you need anti-corrosion performance for the marine environment, that is optional. We adopt to the electrophoresis technology and the multiple coats of marine anti-corrosion paint, the all the mounting brackets and accessories are made of 316 stainless steel. Certified by UL1598A and CCS.

ATEX: EN 60079-0: 2013 ; EN 60079-7: 2015 ; EN 60079-18: 2015 ; EN 60079-28: 2015 ; EN 60079-31：2014;

Warning：

• “WARNING – DO NOT OPEN WHEN ENERGIZED”
• “WARNING – DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE IS PRESENT”
• “WARNING – ONLY USE CABLES SUITABLE FOR 85°C”
• End user shall use certified cable gland or conduit with suitable type of protection for final installation purpose.
• External earthing wire shall be connected when used and the cross-sectional areashall be more than 4mm2 or 10AWG.
• Under rating condition, maximum temperature on the luminaire’s shell shall not be higher than 95℃ for T4.Temperature at cable inlet shall not be higher than allowable limit of the cable applied, to ensure the cable operation normally.

Description:

This explosion proof emergency flood light fixtures with an emergency backup battery (12W Li-ion battery), the emergency backup lighting provide 1680 lumens for the 1.5 hours. For the normal lighting , the input voltage is AC100 - 277V, 20W, 30W, 40W power optional.

This floodlight explosion proof LED fixtures on only obtained IECEx and ATEX certificate, can used for the Zone 1 Zone 21, Zone 2 Zone 22. For design and structure, this emergency explosion proof light made of the die-cast aluminum and the 8mm high tempered glass. Good heat and 6J impact resistance.

If you need anti-corrosion performance for the marine environment, that is optional. We adopt to the electrophoresis technology and the multiple coats of marine anti-corrosion paint, the all the mounting brackets and accessories are made of 316 stainless steel. Certified by UL1598A and CCS.

• Applies to hazardous locations of Zone 1 and Zone2 with explosive gas atmosphere.
• Applies to hazardous locations of Zone 21 and Zone22 with explosive dust atmosphere.

ATEX: EN 60079-0: 2013 ; EN 60079-7: 2015 ; EN 60079-18: 2015 ; EN 60079-28: 2015 ; EN 60079-31：2014;

Warning：

• “WARNING – DO NOT OPEN WHEN ENERGIZED”
• “WARNING – DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE IS PRESENT”
• “WARNING – ONLY USE CABLES SUITABLE FOR 85°C”
• End user shall use certified cable gland or conduit with suitable type of protection for final installation purpose.
• External earthing wire shall be connected when used and the cross-sectional areashall be more than 4mm2 or 10AWG.
• Under rating condition, maximum temperature on the luminaire’s shell shall not be higher than 95℃ for T4.Temperature at cable inlet shall not be higher than allowable limit of the cable applied, to ensure the cable operation normally.

Mounting:

Fix 2 M10 screws on the wall according to the distance between the holes of the bracket. Install the bracket on the screws and then fasten it with the nut. Fix the position of the lamp Place the lamp cord into the pole; connect the wire to local power supply (AC100-277V).

Features:

CES-J120/J150/185 hazardous location emergency light fixtures with an emergency backup battery that provides energy-efficient illumination, the emergency backup provides 1680 lumens for 1.5 hours. For normal lighting, the input voltage is AC100 - 277V, 120W, 150W, 185W power optional, up to 25900-lumen flux. These floodlight hazardous location LED fixtures only obtained UL844, and can use for Class 1 Div 2, Groups A, B, C, and D. For design and structure, these emergency hazardous location LED fixtures are made of die-cast aluminum, and the 8mm high tempered glass. Good heat, and 6J impact resistance.

If you need anti-corrosion performance for the marine environment, that is optional. We adapt to the electrophoresis technology and multiple coats of marine anti-corrosion paint, all the mounting brackets and accessories are made of 316 stainless steel.

Warning：

CUL for Hazloc:

• SUITABLE FOR WET LOCATIONS;
• THIS LUMINAIRE IS ACCEPTABLE FOR OPERATION IN AMBIENT CONDITIONS NOT EXCEEDING 40°C;
• FOR SUPPLY CONNECTION, USE WIRES RATED FOR AT LEAST90°C;
• NO SERVICEABLE PARTS” OR “NO USER SERVICEABLE PARTS. DO NOT OPEN FOR CLEANING.;
• CAUTION - ″TO REDUCE THE RISK OF IGNITION OF HAZARDOUS ATMOSPHERES, DISCONNECT THE LUMINAIRE FROM THE SUPPLY CIRCUIT BEFORE OPENING. KEEP TIGHTLY CLOSED WHEN IN OPERATION.″;
• THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED;
• “CAUTION – RISK OF SHOCK” and “DISCONNECT POWER BEFORE SERVICING”.

UL for marine locations:

• OUTSIDE TYPE or OUTSIDE TYPE (SALT WATER);

Features:

CES-J SERIES hazardous location emergency light fixtures with an emergency backup battery that provides energy-efficient illumination, the emergency backup provides 1680 lumens for 1.5 hours. For normal lighting, the input voltage is AC100 - 277V, 60W, 80W, 100W power optional, up to 14000-lumen flux.

These floodlight hazardous location LED fixtures only obtained UL844, and can use for Class 1 Div 2, Groups A, B, C, and D. For design and structure, these emergency hazardous location LED fixtures are made of die-cast aluminum, and the 8mm high tempered glass. Good heat, and 6J impact resistance.

If you need anti-corrosion performance for the marine environment, that is optional. We adapt to the electrophoresis technology and the multiple coats of marine anti-corrosion paint, all the mounting brackets and accessories are made of 316 stainless steel.

Warning：

CUL for Hazloc:

• SUITABLE FOR WET LOCATIONS;
• THIS LUMINAIRE IS ACCEPTABLE FOR OPERATION IN AMBIENT CONDITIONS NOT EXCEEDING 40°C;
• FOR SUPPLY CONNECTION, USE WIRES RATED FOR AT LEAST90°C;
• NO SERVICEABLE PARTS” OR “NO USER SERVICEABLE PARTS. DO NOT OPEN FOR CLEANING.;
• CAUTION - ″TO REDUCE THE RISK OF IGNITION OF HAZARDOUS ATMOSPHERES, DISCONNECT THE LUMINAIRE FROM THE SUPPLY CIRCUIT BEFORE OPENING. KEEP TIGHTLY CLOSED WHEN IN OPERATION.″;
• THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED;
• “CAUTION – RISK OF SHOCK” and “DISCONNECT POWER BEFORE SERVICING”.

UL for marine locations:

• OUTSIDE TYPE or OUTSIDE TYPE (SALT WATER);

Features:

CES-J40S explosion-proof light fixtures with an emergency backup battery that provides energy-efficient illumination, the emergency backup provides 1680 lumens for 1.5 hours. For normal lighting, the input voltage is AC100 - 277V, 20W, 30W, and 40W power optional.

These floodlight hazardous location LED fixtures only obtained UL844, and can use for Class 1 Div 2, Groups A, B, C, and D. For design and structure, these emergency hazardous location LED fixtures are made of die-cast aluminum, and the 8mm high tempered glass. Good heat, and 6J impact resistance.

If you need anti-corrosion performance for the marine environment, that is optional. We adapt to the electrophoresis technology and the multiple coats of marine anti-corrosion paint, all the mounting brackets and accessories are made of 316 stainless steel.

Warning：

CUL for Hazloc:

• SUITABLE FOR WET LOCATIONS;
• THIS LUMINAIRE IS ACCEPTABLE FOR OPERATION IN AMBIENT CONDITIONS NOT EXCEEDING 40°C;
• FOR SUPPLY CONNECTION, USE WIRES RATED FOR AT LEAST90°C;
• NO SERVICEABLE PARTS” OR “NO USER SERVICEABLE PARTS. DO NOT OPEN FOR CLEANING.;
• CAUTION - ″TO REDUCE THE RISK OF IGNITION OF HAZARDOUS ATMOSPHERES, DISCONNECT THE LUMINAIRE FROM THE SUPPLY CIRCUIT BEFORE OPENING. KEEP TIGHTLY CLOSED WHEN IN OPERATION.″;
• THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED;
• “CAUTION – RISK OF SHOCK” and “DISCONNECT POWER BEFORE SERVICING”.

UL for marine locations:

• OUTSIDE TYPE or OUTSIDE TYPE (SALT WATER);
